| Other Corrugated Hoses |
|
|
| PRODUCT NAME |
TYPE |
MATERIAL |
ID |
OD |
THREAD DISTANCE |
JOINT ID |
JOINT ID |
| Drain HoseΦ26/Φ32 |
PY-P22
|
EVA |
Φ26 |
Φ32 |
4.4 |
Φ21.5 |
Φ21.5 |
| Drain HoseΦ23/Φ35 |
PY-P23
|
Φ23 |
Φ35 |
4.8 |
Φ28 |
Φ28 |
| Drain HoseΦ25/Φ30 |
PY-P24
|
Φ25 |
Φ30 |
3.4 |
Φ21 |
Φ21 |
| Drain HoseΦ29/Φ36 |
PY-P26
|
Φ29 |
Φ36 |
4.0 |
Φ29 |
Φ33 |
|
Features: Products are single-walled corrugated hose, well-structured, soft, light weight, good flexibility, mobility and good toughness; They can be applied in drainage systems for household and industrial equipment. Color and size can be customized according to customer specifications.
| |
 |
 |
 |
 |
| PY-P22 |
PY-P23 |
PY-P24 |
PY-P26 | | |
|
Product name
|
Type
|
Material
|
ID
|
OD
|
Thread distance
|
Joint ID
|
Color
|
| Corrugated hoseΦ13.5
|
PY-P51
|
PP
|
Φ13.5
|
Φ18
|
3.1
|
Φ15
|
Black and grey
|
|
Characteristics: This hose is one-time molding, beauty in appearance with features like lightweight, sufficient compressive strength and impact strength, good flexibility etc; It applies to household and industrial equipment for the drainage systems. Color and size can be customized.
| |
 | | |
|
|
|
Product name
|
Type
|
Material
|
ID
|
OD
|
Thread distance
|
Joint ID
|
| Corrugated hoseΦ26
|
PY-P52
|
PP
|
Φ26
|
Φ33
|
4
|
black
|
|
Characteristics: This is single-wall corrugated hose, beauty in appearance with features such as lightweight, sufficient compressive strength and impact strength, good flexibility etc; It applies to household and industrial equipment for the drainage system. Color and size can be customized.
| |
 | |
|
|
|
Product name
|
Type
|
Material
|
ID
|
¾¶OD
|
Scale
|
Joint ID
|
Extendable length
|
| Folding hoseΦ74/Φ90
|
PY-P53
|
PP
|
Φ74
|
Φ90
|
1:4.5
|
70¡¢75
|
1000
|
| Characteristics: The hose using lightweight materials is compact in structure, having features such as corrosion-resistance and good aging resistance. The operating temperature is between -25 ~ 120 ℃.User can adjust the extendable status according to the need of distance and angle. This hose usually applies to household and industrial equipment for the exhaust system. | |
 | | |
